Gating cells in cytoverse: accessing gated data

Source: vignettes/4_Gating_2.Rmd

Background

In this section we describe the methods available to access and extract the gated data within a GatingSet. It is important to note here that the gates essentially act as filter for the data and may be utilize to subset the original data.

library(flowWorkspace)
library(flowCore)
library(CytoverseBioc2023)
## Warning: replacing previous import 'flowViz::contour' by 'graphics::contour'
## when loading 'flowStats'

Gating paths: get and set

Let’s first look at the gates that are attached to the GatingSet. For this example, we will make use of a GatingSet that we have previously prepared.

gs <- make_transformed_gs(add_gates = TRUE)
gs
## A GatingSet with 4 samples

We have previously used plot(gs) to visualize the gating hierarchy as a tree as shown below:

To extract the full gating path we can use gs_get_pop_paths method.

# get all paths
gs_get_pop_paths(gs)
##  [1] "root"
##  [2] "/singlet"
##  [3] "/singlet/live"
##  [4] "/singlet/live/lymphocytes"
##  [5] "/singlet/live/lymphocytes/CD3+ T cells"
##  [6] "/singlet/live/lymphocytes/CD3+ T cells/NKT cells"
##  [7] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells"
##  [8] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells"
##  [9] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/MAIT Cells"
## [10] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT"
## [11] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon"
## [12] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4-CD8a+"
## [13] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4+CD8a+"
## [14] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4+CD8a-"
## [15] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4-CD8a-"

When there are a lot of gates, this list can become very long as each node is shown as a distinct path. Suppose you would like to only view the leaf nodes. For this, we use gs_get_leaf_nodes.

# get leaf nodes
gs_get_leaf_nodes(
  gs,
  ancestor = "root") # can select leafs of a specific node
## [1] "/singlet/live/lymphocytes/CD3+ T cells/NKT cells"
## [2] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/MAIT Cells"
## [3] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT"
## [4] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4-CD8a+"
## [5] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4+CD8a+"
## [6] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4+CD8a-"
## [7] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4-CD8a-"

To change the name of a node, for instance, CD4-CD8a- above is not super clear and we want to update this to Double Negative CD3+ T cells for readability, we can use gs_pop_set_name method.

# rename node
gs_pop_set_name(
  gs,
  "CD4-CD8a-",
  "Double Negative CD3+ T cells")
## $`4000_TNK-CR1`
## NULL
##
## $`4001_TNK-CR1`
## NULL
##
## $`4002_TNK-CR1`
## NULL
##
## $`4003_TNK-CR1`
## NULL
# check
gs_get_leaf_nodes(gs)
## [1] "/singlet/live/lymphocytes/CD3+ T cells/NKT cells"
## [2] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/MAIT Cells"
## [3] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT"
## [4] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4-CD8a+"
## [5] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4+CD8a+"
## [6] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/CD4+CD8a-"
## [7] "/singlet/live/lymphocytes/CD3+ T cells/non-NKT Cells/conv_Tcells/not_MAIT_Polygon/Double Negative CD3+ T cells"

Exercise

  1. Run gs_get_pop_paths(gs) by include a path = 1 argument. How is the output different compared to not providing path? What happens when you change this to path = 2?
  2. Suppose you do not know what is the parent population for Double Negative CD3+ T cells, what is an easy approach to get this information? Hint: Try help(gs_pop_get_paths) to check other available methods.

Extracting filtered data

Often, users may also want to extract the embedded expression data for a specified gated population for some downstream application. The cytoverse makes it super easy to extract this data. Moreover, the extracted data is preserved as a cytoframe or a cytoset for ease of use.

The 2 main methods are: 1. gs_pop_get_data 2. gh_pop_get_data

# extract data
extracted <- gs_pop_get_data(gs,
                y = "live",
                inverse.transform = FALSE)
extracted
## A cytoset with 4 samples.
##
##   column names:
##     FSC-A, FSC-H, SSC-A, B515-A, B610-A, B660-A, B710-A, B780-A, G575-A, G610-A, G660-A, G710-A, G780-A, R670-A, R730-A, R780-A, U390-A, U450-A, U500-A, U570-A, U660-A, U740-A, U785-A, V450-A, V510-A, V570-A, V605-A, V655-A, V710-A, V750-A, V785-A, remove_from_FS_FM, Time
##
## cytoset has been subsetted and can be realized through 'realize_view()'.

Exercise

  1. Try running the above code as gh_pop_get_data. How are the results different?
  2. Extract the data from the gate Double Negative CD3+ T cells for the 1st sample and store it as sample_1. Transform the expression value for FSC-A. What happens to the data in gs?Hint
# plot
ggcyto(gs,
       subset = "Double Negative CD3+ T cells",
       aes(x = "FSC-A", y = "SSC-A"))+
  geom_hex(bins = 256)
Notice that altering the extracted data leads to altered data within the GatingSet. This is because we did not create a new copy of the data using realize_view method. Importantly, this further highlights that the cytoframe, cytoset, and the GatingSet are all pointing to the same data!
  1. what does inverse.transform argument do?
  2. Run the following code:

This is only for example.

another_CD3_gate <- matrix(c(-Inf,Inf), nrow = 2, ncol=1)
colnames(another_CD3_gate) <- "FSC-A"
another_CD3_gate <- rectangleGate(.gate = another_CD3_gate, filterId = "CD3+ T cells")
gs_pop_add(gs, parent = "non-NKT Cells", gate = another_CD3_gate)
recompute(gs)
plot(gs)

Now try to extract the CD3+ T cells population using either gs_ or gh_ methods as above.

Saving extracted data

Depending on the method called, the extracted data is either preserved as a cytoframe or a cytoset. As you experienced in the exercise, manipulating the extracted without performing a deep copy using realize_view leads to alteration of the data within the GatingSet object. As such, if extracting for further downstream application, it maybe worthwhile to save the data. For this, please refer to the Importing and Basics of working with FCS files for more details.

Conclusion

In this brief section we demonstrated how users/analysts could extract the embedded data from a GatingSet. Feel free to explore the flowWorkspace vignette for additional available methods. In the next section, Reporting, we will go over how to extract various statistics regarding the gated populations.
